Levelling, Loading & Transport
Front Loader with Backhoe
Fits tractors of 35–90 HP, with buckets and hydraulics that can be tailored to the job.
- Tractors 35–90 HP
- Tailored set-up
- Safety features
About this product
How the Front Loader with Backhoe works
This front loader with backhoe is a versatile attachment for loading, digging, trenching and general material handling. It is built for durability and easy maintenance, and it can be matched to a wide range of tractors.
The loader bucket holds 0.35–0.60 m³ and lifts 800–1,200 kg at full height; the backhoe digs 2.0–3.5 m deep with buckets of 0.05–0.25 m³. It needs 30–70 L/min of hydraulic flow, uses joystick or manual-lever control, and has a high-strength steel frame, relief valves and stabiliser legs. Weight is roughly 800–1,400 kg, and quick-couplers, pallet forks, a grapple, extended booms and a canopy are available.
Because compatibility depends on the model and the tractor, send us your tractor details first. Loader lift is 800–1,200 kg and backhoe depth 2.0–3.5 m, and the hydraulic flow required is 30–70 L/min. Optional pallet forks, a grapple and extended booms turn it into a general-purpose handler.
Before you buy the Front Loader with Backhoe
This combination gives one tractor both lifting and digging. It fits tractors from 35 to 90 HP, and the buckets and hydraulics can be matched to your work. It is a good fit for farms and contractors who need a versatile machine without buying a full backhoe loader.
Specifications
Specifications
Front Loader with Backhoe: the specifications
| Compatibility | Tractors 35 – 90 HP (check model fitment) |
|---|---|
| Mounting | Rear-mounted backhoe & front loader — fits 3-point hitch (Cat I/II) / loader subframe |
| Loader bucket capacity | 0.35 – 0.60 m³ (various bucket widths available) |
| Loader lift capacity (at full height) | 800 – 1,200 kg (depending on tractor and model) |
| Backhoe digging depth | 2.0 – 3.5 m (model-dependent) |
| Backhoe bucket sizes | 0.05 – 0.25 m³ (multiple widths for trenching or digging) |
| Hydraulic requirements | Standard tractor hydraulic flow 30 – 70 L/min (additional flow options available) |
| Control | Joystick / manual lever hydraulic control options |
| Construction | High-strength steel frame; reinforced loader arms and backhoe boom |
| Safety features | Relief valves, stabilizer legs for backhoe operations, operator protection options |
| Weight (approx.) | 800 – 1,400 kg (varies by configuration) |
| Optional extras | Hydraulic quick-couplers, pallet forks, grapple, extended reach booms, canopy/ROPS |
| Customization | Buckets, hydraulic flow, control type and mounting adapters can be tailored to your tractor and tasks |
Sizes available
Need another size of the Front Loader with Backhoe?
Ask about sizesKey features
Key features of the Front Loader with Backhoe
Tractors 35–90 HP
Fits a wide range of tractor sizes.
Tailored set-up
Buckets, hydraulics and controls can be matched.
Safety features
Relief valves and stabiliser legs.
Questions
Questions about the Front Loader with Backhoe
Yes, this combination uses a front loader and a rear-mounted backhoe on tractors from 35 to 90 HP. Check your tractor's compatibility before ordering.
