Boom Sprayer
Wide, even coverage for pesticides, repellents and nutrients.
- Wide boom
- Agitation system
- Fast filling
About this product
How the Boom Sprayer works
The boom sprayer is a tractor-mounted, PTO-operated sprayer for applying pesticides, repellents and nutrients across a wide range of crops. Tanks of 500 to 1,000 litres, in durable fibreglass or plastic, give you the right amount for the job.
A spray boom of 42.5 to 55 feet carries 24 to 34 hollow-cone nozzles, fed by a PTO-driven diaphragm pump delivering 100 L/min, with stainless-steel filters at the tank inlet, pipes and each nozzle. The tank fills in about 8 minutes, boom height and width are adjustable, and the sprayer covers 8–10 acres an hour with tractors of 50–85 HP and more. Total weight with boom is 240 to 400 kg.
Calibrate the sprayer before every season: measure the output of each nozzle and replace any that differ noticeably. Choose the tank size for your fields (500–1,000 L) and a boom length of 42.5 to 55 ft, and never spray in strong wind. Wear protective clothing and follow every chemical's label.
Before you buy the Boom Sprayer
A boom sprayer gives even coverage across wide fields, which saves time and chemical. Choose the tank size and boom length to match your acreage, and think about the tractor's power. Training operators in calibration is just as important as the machine itself.
Specifications
Specifications
Boom Sprayer: the specifications
| Tank Capacity | 500 L – 1,000 L |
|---|---|
| Tank Material | Fiber Glass with Agitation System |
| Spray Boom Length | 42.5 to 55 feet |
| Pump Type | Diaphragm type to be operated with PTO |
| Pump Speed | 500 RPM |
| Pump Output | 100 L/min |
| Nozzle Type and Number | Hollow Cone Type |
| Number of Nozzles | 24 to 34 |
| Total Weight with Boom | 240 to 400 kg |
| Transportation Width | 9 ft |
| Height of Filling | 4.75 ft |
| Time of Tank Filling | 8 min |
| Filters | Stainless steel filters in different parts of sprayer: tank inlet, pipes, each nozzle |
| Output | 8 – 10 Acre/Hr |
| Tractor Compatibility | 50 HP – 85 HP & more |
| Operation | Easy to operate, manual operation |
| Adjustments | Adjustable boom height and width |
| Additional Features | Multiple nozzles or spray tips, fiber tank |
Sizes available
Need another size of the Boom Sprayer?
Ask about sizesKey features
Key features of the Boom Sprayer
Wide boom
42.5 to 55 ft with 24–34 nozzles.
Agitation system
Keeps the mix even in the fibreglass tank.
Fast filling
About 8 minutes to fill the tank.
Questions
Questions about the Boom Sprayer
Tank sizes run from 500 to 1,000 litres and the boom length is 42.5 to 55 feet, which gives wide, even coverage for field crops.
